Camera
|
| Image Sensor |
1/2.8”8Megapixel progressive CMOS |
| Max. Resolution |
3840 (H) × 2160 (V) |
| ROM |
128 MB |
| RAM |
512 MB |
| Scanning System |
Progressive |
| Electronic Shutter Speed |
Auto/Manual 1/3 s–1/100,000 s |
| Min. Illumination |
0.007 Lux @F1.5 |
| S/N Ratio |
>56 dB |
| Illumination Distance |
50 m (164 ft) |
| Illuminator On/Off Control |
Auto/Manual |
| Illuminator Number |
2 (IR LED) |
| Pan/Tilt/Rotation Range |
Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360° |
Lens
|
| Lens Type |
Motorized vari-focal |
| Mount Type |
φ14 |
| Focal Length |
2.7 mm–13.5 mm |
| Max. Aperture |
F1.5 |
| Field of View |
Horizontal: 113°–31°
Vertical: 58°–17°
Diagonal:138°–36° |
| Iris Type |
Fixed |
| Close Focus Distance |
0.8 m (2.6 ft) |
| DORI Distance |
Lens |
Detect |
Observe |
Recognize |
Identify |
| W |
85.3 m (279.9 ft) |
34.1 m
(111.9 ft) |
17.0 m
(55.8 ft) |
8.5 m
(27.9 ft) |
| T |
280.0 m (918.6 ft) |
112.0 m (367.5 ft) |
56.0 m
(183.7 ft) |
28.0 m
(91.9 ft) |
Professional, intelligent
|
| Perimeter Protection |
Tripwire; intrusion (support the classification and accurate detection of vehicle and human) |
| Intelligent Search |
Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos. |
Video
|
| Video Compression |
H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream) |
| Smart Codec |
Smart H.265+/ Smart H.264+ |
| Video Frame Rate |
Main stream:
3840 × 2160 @(1–20 fps by default)
3840 × 2160 @(1–25/30 fps when AI function disabled)
sub stream:
704 × 576 @(1–25 fps)/704 × 480 @ (1–30 fps)
third stream:
1920 × 1080 @(1–25/30 fps) |
| Stream Capability |
3 streams |
| Resolution |
8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240) |
| Bit Rate Control |
CBR/VBR |
| Video Bit Rate |
H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps |
| Day/Night |
Auto (ICR)/Color/B/W |
| BLC |
Yes |
| HLC |
Yes |
| WDR |
120 dB |
| Scene Self-adaptation |
Yes |
| White Balance |
Auto/natural/street lamp/outdoor/manual/regional custom |
| Gain Control |
Auto/Manual |
| Noise Reduction |
3D DNR |
| Motion Detection |
OFF/ON (4 areas, rectangular) |
| Region of Interest (RoI) |
Yes (4 areas) |
| Smart Illumination |
Yes |
| Image Rotation |
0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.) |
| Mirror |
Yes |
| Privacy Masking |
4 areas |
Audio
|
| Built-in MIC |
Yes |
| Audio Compression |
G.711a; G.711Mu; G726; AAC |
Alarm
|
| Alarm Event |
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; SMD; safety exception |
Network
|
| Network |
RJ-45 (10/100 Base-T) |
| SDK and API |
Yes |
| Protocol |
IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP |
| Interoperability |
ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec |
| User/Host |
20 (Total bandwidth: 72 M) |
| Storage |
Dahua Cloud (only supported by Dahua version); FTP; SFTP; Micro SD card (support max. 256 G); NAS |
| Browser |
IE: IE8; IE9; IE11
Chrome
Firefox |
| Management Software |
Smart PSS; DSS; DMSS |
| Mobile Phone |
IOS; Android |
Certification
|
| Certifications |
CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07 |
Power
|
| Power Supply |
12V DC/PoE (802.3af) |
| Power Consumption |
Basic power consumption: 2.6W (12V DC); 3.3W (PoE)
Max. power consumption (WDR + H.265 + IR LED intensity): 6W (12V DC); 7.3W (PoE) |
Environment
|
| Operating Conditions |
–30°C to +60°C (–22°F to +140°F)/Less than 95% RH |
| Storage Conditions |
–40°C to +60°C (–40°F to +140°F) |
| Protection Grade |
IP67 |
Structure
|
| Casing |
Metal |
| Dimensions |
108.3 mm × Φ122 mm (4.3″ × Φ4.8″) |
| Net Weight |
685g (1.5 lb) |
| Gross Weight |
828 g (1.8 lb) |
